Garden Play Fort with Cargo Net and Swing Extension : GPFX-N

Description

This Garden Play Fort with Cargo Net and Swing Extension has a central unit constructed from timber with a 3.0m HDPE wave slide, two access ladders and a climbing ramp with pull rope. It also has a double swing frame with extension on one side which has two double swing points and a single swing point on the extension. On another side of the tower is a large climbing net frame with hemp rope net. This product really does have it all!

All the timbers have been pressure treated and impregnated with wax, providing a more repellent surface so reducing water absorption and delaying future rotting of the timber. The ropes used on the net and swings are poly hemp which means they are soft to touch, natural looking and waterproof therefore able to withstand the weather and therefore less liable to rot.

Swing seats are purchased separately to enable you to choose the right seat combination for the size, age and ability of the persons using the product so don’t forget to buy swing seats! Information on choosing swing seats for different types of swing points is available here.

We recommend using Grass Safety Mats under and around this product in order to prevent ground erosion and reduce the chance of injury should a child fall.

Here is a lovely post on Facebook by a Caledonia Play customer who bought our Garden Play Fort with Cargo Net and Swing Extension.

Some of the images show the product without the ramp added on, however, our Garden Play Fort with Cargo Net and Swing Extension does come with a climbing ramp and pull rope as standard.

Take a look at our gallery of Alternative Forts for inspiration if you’re looking for something more bespoke.

“You guys need to enable the reviews thingy on here so I can write you up with 5-stars! Our new play set is fab, the boys are just thrilled with it. I’ve also been seriously impressed with your service – the whole process was smooth and pleasant from beginning to end. Thank you so much!”

Delivery: Please note that due to the size and weight of this product, delivery and installation can be between 4-8 weeks. Please call the office on 01577 840570 to find out more information or if one of our own drivers will be heading to your area in which case your delivery might arrive sooner.



Specification

The GPF tower is constructed with 6 legs, (8cm machine rounded timber) with a set of support bars that create a secure frame structure.

The tower platform floor is machined redwood decking position 1.4m above ground level.

The tower is accessed via two 5 rung ladders and climbing ramp.

All rungs are positioned 25cm apart and have red safety bushes between the rungs and ladder sides.

The 3m climbing ramp can be positioned on either side of the tower. – opposite to the swing frame

A swing frame is can be attached to the tower by 10M timber bolts fixed to the corner and centre legs.

Top swing pole 12cm diameter supported by two pairs of 10cm diameter legs

Top pole secured with 10M timber bolts and 8M timber bolts are used at all other points, - located into pre-drilled recessed holes.

2.5m spread between the 10cm diameter legs – very stable.

8cm diagonal bracing bars have 2 fixing points at end of the bar

All swing pivot points are fixed through 12cm top swing pole, locked with twin locking nuts.

All swing ropes are 12mm and sealed and tested to 200kg

The hemp rope net is 1.2m wide x 3.0m and ladder 1.0m wide

The roof size is 1.8 x 1.8m

The play frame can be changed to have either 2 nets or 2 ladder sets.

All steps are 6cm diameter and positioned 28cm apart and have red safety bushes between the rungs and ladder sides, (frame legs)

All the timbers have been pressure treated and impregnated with wax, providing a more repellent surface so reducing water absorption and delaying future rotting of the timber.

Due to the size of the A-frame legs they are able to partially compensate for uneven ground or slight slopes.

The wave slide is 3m long and is made of high-density polyethylene.

Dimensions

Length: 7.5m | Width: 5.5m | Height: 3.2m including tower with swing extension, slide, net frame, ladder and access ramp

Length: 1.5m | Width: 1.5m | Height: 3.2m Tower size only

Roof: 1.8 x 1.8m

Platform height: 1.5m

Website Footprint DO GARDEN PLAY FORT GPFXN

Please note: dimensions are approximate and for guidance only - sizes will vary depending on the configuration, the chosen angle of the access ramp and ladder and net and if the product is placed on sloping ground.
